leak!!! and how to fix?

Discussion in 'Modifications And Maintenance' started by jing123, Aug 29, 2008.

  1. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    so guys there is a leak near my turbo i dont know what it is or where exactly but my car smokes because it touches the header any ideas and any solutions many thanks

  2. Yang
    Offline

    Yang Well-Known Member

    Messages:
    2,027
    Likes Received:
    3
    Trophy Points:
    223
    Location:
    mpls
    oil or coolant leak?

  3. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    im not sure if its oil or coolant its right next to the turbo so im not all that great with the subie engines yet sorry

  4. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    seems like oil tho

  5. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    any ideas guys im in a tough bind dont wanna drive the car while there is a leak

  6. modsuby
    Offline

    modsuby New Member

    Messages:
    267
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Lino Lakes, MN
    check your inner axle boot, grease will land on the exhaust and smoke and stink. you might need a light but look from underneath if you cant see from up top.

  7. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    checked that to but everything there is fine. it looks like its comin from the top but no idea where when i open the hood just that little area is all wet and it stinks soemwat like coolant but its brown in color so im not sure what it is and where its comin from

  8. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
  9. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    i think its in that area tat its leakin and sorry for the big pic

  10. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
  11. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    any ideas?

  12. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    got anything guys

  13. Scuba Steve
    Offline

    Scuba Steve Well-Known Member

    Messages:
    9,517
    Likes Received:
    4
    Trophy Points:
    173
    Location:
    In the Co-Driver Seat
    what year, make, model? 02-03 wrx?

    Looks like the hard Oil line for turbo. The oil originates there and travels up and around and into the turbo. If that's the case it's a super easy fix, just replace the washer...more than likely. (or hardline and hardware)

  14. Daveo
    Offline

    Daveo Well-Known Member

    Messages:
    175
    Likes Received:
    0
    Trophy Points:
    101
    Location:
    Roseville, MN
    Oil will smell like, well, burning oil, and coolant will smell sweet, kind of like maple syrup.

  15. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    it had a sweet smell to it and it was black like oil so yea not sure and its a 01 but tats the 05 motor thanks

  16. AWDimprezaL
    Offline

    AWDimprezaL has more posts than you

    Messages:
    16,479
    Likes Received:
    1,821
    Trophy Points:
    573
    Gender:
    Male
    Location:
    Monticello.
    if it was sweet, but black like oil then its nothing that should be in your engine.


    My guess is that you have a coolant leak from somewhere else, but you are seeing smoke from a leaking oil line

  17. aspiringRexer
    Offline

    aspiringRexer Member

    Messages:
    263
    Likes Received:
    0
    Trophy Points:
    26
    ^^

    OP: Check your oil. If it looks milky, you've got coolant getting into the oil and therefore a leaking head gasket on top of the oil leak.

    It's like getting hit by a car, only to have the hospital tell you that you've got rabies too. Perhaps a fun-run is in order for the OP.

  18. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    lol im sure its not oil because its not thick like oil and the only other option left is coolant but im not sure where that coolant is coming from since its near the turbo

  19. Scuba Steve
    Offline

    Scuba Steve Well-Known Member

    Messages:
    9,517
    Likes Received:
    4
    Trophy Points:
    173
    Location:
    In the Co-Driver Seat

    well there are two coolant lines for the turbo. Incoming is the top line, return is the bottom. Both are located on the side of the turbo. trace the lines.

    don't you have anyone that can help you?

  20. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    well the thing is that i dont know where to start lookin because it only leaks after hte car warms up and im driving it. if i let it sit itll be fine. its to hot around that area to go searchin when i can see the leak and when i cant see it i dont know where to look i checked the wires but it doesnt seem to be leaking when u touch anywhere around it. at the moment no i dont have anyone to help

  21. TSTRBOY2004
    Offline

    TSTRBOY2004 Well-Known Member

    Messages:
    12,202
    Likes Received:
    403
    Trophy Points:
    393
    Gender:
    Male
    Location:
    Jordan, Minnesota, United States
    degrease it very well..... let it dry then go drive it till you see a small leak... so you cna be sure where it is coming from... or without sounding like an ass... the time you have spent asking 10 times how to fix somethign which no-one knows exactly what the problem is, is like asking chet to check your oil or fill er up with gas... POINTLESS!!!

    go to FS or meet someone so they can look at it in person

  22. jing123
    Offline

    jing123 Well-Known Member

    Messages:
    913
    Likes Received:
    38
    Trophy Points:
    213
    hey guys thanks alot for the input and i have found the problem. it wasnt any leak near the turbo it was just the coolant leaking in the front that travelled along the headers while i was driving and it hit the uppipe where there was no heat shield so yea just tighten so loose nuts and hopefully that does the trick

  23. aspiringRexer
    Offline

    aspiringRexer Member

    Messages:
    263
    Likes Received:
    0
    Trophy Points:
    26
    Warm oil is like water.
